Syvecs Yahama YXZ1000R - S7Plus Plug in ECU

Code: S7Plus-YAMXYZ

The Syvecs Yamaha XYZ Kit brings a new level of engine management control to the Yamaha XYZ range with a complete standalone engine control module.
This covers the Base and also SS Paddleshift model.

In Stock

Description



The Syvecs Yamaha YXZ Plug N Play Kit brings a new level of engine management control to the YXZ range with a complete standalone ECU for both the base and the SS paddleshift model.
By simply pluging in the kit, a whole new level of control is available and the following Syvecs features become available:

Syvecs Yamaha YXZ Features:

- Flat Shift/GearCut if using a LoadCell sensor on base model

- Support for SS paddleshift model

- Flex Fuel control.

- Fully functional with every other ECU on the car.

- Closed loop Lambda control.

- DBW support with cruise control (Optional only if the correct parts are fitted)

- Rolling antilag / pit lane limiter strategies, great for building boost on a roll.

- Adjustable traction control strategies based on lateral G and individual wheel speed monitoring.

- Adjustable launch control.

- 12 switchable maps with the aility to select desired engine map, boost level, traction and launch control levels through an optional rotary switch

- Secondary injector option for 6 injector control

- Knock control when Bosch sensor is fitted

- Live tuning of every aspect of the engine’s calibration.

- Fully adjustable closed loop boost control with launch level adjustments and trims for turbo speed, air charge, engine coolant temp, exhaust gas temps etc..

- Built in data logging using a market leading analysis software of up to 8 hours, with data rates at up to 1000hz.

- Anti-theft and valet modes.

- Super fast connection via RJ45 Ethernet port for live tuning anywhere in the world or even remotely if on track if connected to a wireless unit.

- Configurable engine safety trips on all important parameters like oil temperature, oil pressure.

- Fuel pump control of both main, and sub pumps, as well as relative fuel pressure monitoring and limiting in the event of fuel pressure dropping on boost.

- Run up to 7bar map sensors.

- Control high or low impendence injectors.

- Ability to fit any type of external sensor to monitor and trigger safety trips from anything from crank case pressure to damper position.

- Ability to use any size DBW throttle body e.g. Chevrolet LS7.

- Wet and Dry – Wet and dry nitrous control with ability to drive solenoids directly and control n20 heaters via pressure monitoring.

- Ability to control any external vehicle features based on sensor inputs e.g. Adjustable rear wing linked to G force or exhaust control valves.

- Connect any race series dash or even one of our Syvecs edition SDM display units.

- View any input live with built in scope up to 1000hz.

And much, much more!

See the Kit in action below



Additional information

Installation Manual

http://www.syvecs.com/downloads/Syvecs_Yamaha_XYZ_Manual.pdf

Software

http://www.syvecs.com/forum/viewtopic.php?f=8&t=122
